A control room sized from signal counts, not guesswork
Barmaan uses this tool to size its own control rooms: give it the I/O count, the plant footprint and the distance to the building, and it computes the PLC cards, cabinets, room areas, cable metre take-off, power and HVAC loads, and a priced bill of materials — then draws the result in 3D and as a real DXF file.
The numbers and the 3D model below are the actual output of the engine on a real, seeded project — nothing on this page is a drawn-up illustration.
Who this is for
Four people ask four different questions
EPC contractor / project engineer
How big does the control building actually need to be?
The room list (control room, rack room, UPS room, HVAC room) and its net and gross area come straight out of the signal count and operator positions you give it.
Instrumentation & automation engineer
How many PLC cards, stations and cabinets does this I/O list need?
AI/AO/DI/DO channels are turned into card counts, station counts and system/network/power/ESD cabinets, with the design spare already applied.
Procurement / panel vendor
What do I actually price — and against which real offers?
A bill of materials with catalogue specs, order numbers and quantities, priced against researched market offers for the PLC, SCADA licence, cabinets, UPS and cable.
Owner / project sponsor
Can I see the layout before a single desk or cabinet is ordered?
The same design opens as a clickable 3D model of the site and the building further down this page — no CAD software needed to check it.
What the engine actually computes
One set of inputs, six real outputs
Every number below comes out of the same pure sizing engine (`src/lib/control-room/engine.ts`) the admin studio runs — this page reads its output, it does not recompute anything separately.
I/O, cards and stations
Wired AI/AO/DI/DO channels plus a design spare, turned into PLC card counts and I/O station counts.
Cabinets and room areas
System, network, power and (optional) ESD cabinets, sized from the card count, and the control room, rack room, UPS and HVAC room areas sized from cabinet count and operator positions.
Cable metre take-off
Field-to-junction-box branch cable and junction-box-to-building homerun cable, both computed from the plant footprint and the routing factor, with a junction-box count per signal family.
Power and HVAC load
Electrical load and the UPS size it calls for (rounded to a standard frame), plus the heat and cooling load the room's air conditioning has to carry.
Priced bill of materials
Every line — PLC CPU, I/O cards, SCADA licence, operator consoles, cabinets, UPS, cable, cable tray, junction boxes — priced from a real catalogue, with an economy/standard tier and researched market offers per item.
3D layout, DXF and P&ID sheet
The same site and building layout renders as a clickable 3D model, exports as an AutoCAD-openable DXF file, and can generate a schematic P&ID sheet of the site using Barmaan's own P&ID drawing engine.
Real numbers, one real project
A real naphtha-unit control roomsample projectThis is the actual, saved input set for a real control-room project (a naphtha unit's control building), run through the engine above.
- Design I/O channels
- 118
- Cabinets
- 3
- Building area (gross)
- 91 m²
- Cable tray length
- 302 m
- Electrical load
- 2.3 kW
- UPS size
- 5 kVA
Interactive — try it yourself
The same design, in 3D
Drag to rotate, scroll to zoom, and click any room, cabinet, console or site tank to see what it is. Nothing here is saved — this is the same read-only demo also shown on the QC engineering page.
The control room — click a part of the site
A real, seeded control-room sizing (naphtha unit): the plant, the field junction boxes, the trunk route in, and the control building with its racks and operator consoles. Click any part to see what it is.
Right-drag: rotate · left-drag: pan · wheel: zoom · click: select a part
Want this sized for your project?
Ask us to size a control room for your project
Tell us the I/O count, the plant size and the distance to the building — we run the same engine, review the BOM and hand over a 3D layout and a DXF file.
